お支払い方法の種類: | L/C,T/T,D/P,Paypal,Money Gram,Western Union |
---|---|
インコタームズ: | FOB,CFR,CIF,EXW |
ブランド: Taihang Jiaxin
包装: 木箱かカートン
生産高: 50-200 units / month
輸送方法: Ocean,Land,Air
原産地: 中国
についてのサポート: 50-200 units / month
認証 : ISO9001.CE
HSコード: 8504401990101
ポート: Tianjin-by Sea,Shanghai-by Sea,Zhengzhou-by Air
お支払い方法の種類: L/C,T/T,D/P,Paypal,Money Gram,Western Union
インコタームズ: FOB,CFR,CIF,EXW
モデルの説明
Input Voltage |
AC220V±15%,50Hz 1-phase, 3-wire |
|
Input Power |
2.0KW |
2.0KW |
Output Valtage |
DC0V~32V |
DC0V~64V |
Output Current |
DC 0A~60A |
DC 0A~30A |
Efficiency |
≥94% |
|
Power Factor |
≥0.99(Full Load Condition) |
|
Voltage Precision |
±0.5% |
|
Current Precision |
±0.5% |
|
Ripple |
0.5% |
|
Over Temperature Protection Value of Rectification Unit |
80-85℃ |
|
Protection |
Over-voltage, over-current, short circuit, over-temperature, battery reversal |
|
Insulation |
20KΩ |
|
Voltage Withstanding between Input and Housing |
AC200KV(1 minute) |
|
Voltage Withstanding between Input and Output |
AC200KV(1 minute) |
|
Voltage Withstanding between Output and Housing |
AC200KV(1 minute) |
|
MTTF(Mean Time to Faliure) |
50000 hours |
|
External Dimensions |
H190mm×W160mm×D345mm(TypeA) |
H190mm×W160mm×D345mm(TypeB) |
Weight |
10Kg (Type A) |
10Kg (Type B) |
